Touchscreen Modular PLC Control Cabinet

Material: Stainless steel
Color: black
Place of Origin: Shanxi, China
Application: Industrial
Product Category: Industrial Automation Control

This touch‑screen modular PLC control cabinet is suitable for AC 380V/220V low‑voltage distribution systems. Built with a modular structure, it integrates touch‑screen HMI, PLC controller, low‑voltage power distribution, intelligent control and data acquisition functions. PLC modules, touch screen and power‑distribution components can be flexibly configured within the cabinet. It offers multi‑protection against overload, short‑circuit, earth‑leakage, over‑voltage and under‑voltage. Visualized operation, status monitoring and fault diagnosis of equipment can be completed via the touch screen. It satisfies control and power‑distribution requirements for industrial automation, intelligent equipment and building automation applications.

‑ Rated Voltage: AC 380V/220V
‑ Rated Current: 100A ~ 2500A (customizable)
‑ Poles: 4P
‑ Protection Class: IP30
‑ Short‑circuit Withstand Current: ≥30kA‑80kA
‑ Compliance Standards: GB 7251.1, IEC 61439‑1
‑ Standard HMI: 7‑inch / 10‑inch / 15‑inch touch screen, supporting Chinese‑English language switching, data display, parameter setting and fault alarming
‑ Supported PLC Brands: Siemens, Mitsubishi, Omron and other mainstream brands
‑ Structure: Modular design for flexible configuration of PLC modules and power‑distribution components
‑ Protection Functions: overload, short‑circuit, earth‑leakage, over‑voltage, under‑voltage and phase‑loss protection
‑ Communication: Multiple protocols supported for connection to host computers and SCADA systems

① Visualized operation via standard‑equipped touch screen. It enables parameter configuration, status monitoring, fault diagnosis and manual‑automatic mode switching. The intuitive human‑machine interface allows operation without professional programming expertise.
② Modular construction supports flexible configuration of PLC controllers, touch screens and power‑distribution components. Customization is available for varied equipment control requirements to fit diverse industrial scenarios.
③ Integrated power distribution and control. It delivers both low‑voltage power supply and automatic equipment control. Separate distribution cabinets and control cabinets are no longer required, which simplifies system design and cuts overall costs.
④ Comprehensive protection including overload, short‑circuit, earth‑leakage, over‑voltage, under‑voltage and phase‑loss protection to fully secure equipment and system operation.
⑤ Data storage and traceability supported. The touch screen stores equipment operating data and fault logs for subsequent analysis, maintenance and production‑data tracing.

‑ Equipment control for industrial automated production lines
‑ Intelligent machine‑tool control
‑ Control for automated packaging equipment
‑ Printing equipment control
‑ Textile machinery control
‑ HVAC control for building automation systems
‑ Waste‑water treatment equipment control
‑ Control for automated food and beverage processing equipment

Q1: What functions can this touch‑screen PLC control cabinet perform?

A: It supports visualized equipment operation, running‑status monitoring, parameter setting, fault alarm & diagnosis, and manual‑automatic mode switching through the touch screen. Integrated with low‑voltage power‑distribution functions, it provides stable power supply for equipment and realizes combined power distribution and control.

Q2: Which PLC brands are compatible?

A: Mainstream domestic and international PLC controllers are supported, including Siemens, Mitsubishi, Omron and Delta. Units can be selected according to customer requirements.

Q3: Does it support data storage and traceability?

A: Data storage comes as standard. The touch screen records equipment runtime data, fault logs and production parameters. Historical data can be retrieved and traced to facilitate production management and equipment maintenance.
